GNT GB30CS-145Li Series Lithium Straddle Stacker

3,000 LB CAPACITY | LIFT AND STACK HEAVY PALLET LOADS

The GNT GB30CS-145Li delivers 3,000 lbs of lifting capacity for demanding warehouse and material handling work. It is built for loading docks, stock rooms, manufacturing floors, and warehouses where dependable pallet lifting is needed.

145 INCH LIFT HEIGHT | REACH HIGH STORAGE LOCATIONS

The 145-inch raised height gives the GB30CS-145Li the reach needed for higher pallet storage. This helps you make better use of available vertical space while keeping loads under control.

SIDE-SHIFT FORK SYSTEM | POSITION PALLETS WITH PRECISION

The side-shift design lets you adjust pallet position without moving the entire machine. This makes it easier to line up loads accurately when working in tight storage areas.

LITHIUM-ION POWER | FAST CHARGING WITH ZERO MAINTENANCE

The 24V/90Ah lithium battery provides long-lasting power with fast charging and zero battery maintenance. This helps simplify daily operation and keeps the stacker ready for repeated material handling work.

39.76-55.55 INCH ADJUSTABLE LEGS | FIT DIFFERENT PALLET WIDTHS

The adjustable legs can be positioned from 39.76 to 55.55 inches. This gives the operator more flexibility when working with different pallet sizes and load positions.

45.3 INCH FORKS | SOLID PALLET SUPPORT

The 45.3-inch forks provide the reach needed to support palletized loads during lifting and movement. The adjustable fork width from 8.66 to 32 inches adds flexibility for different load configurations.

24V AC DRIVE SYSTEM | SMOOTH POWER FOR DAILY OPERATION

The 24V AC drive motor provides controlled power for moving loads around the work area. The Curtis controller works with the drive system to support precise machine operation.

ERGONOMIC CONTROLS | EASIER OPERATION THROUGH LONG SHIFTS

The ergonomic handle and controls put key functions within easy reach. This helps the operator control lifting and travel without unnecessary movement.

STEEL CONSTRUCTION | BUILT FOR DEMANDING MATERIAL HANDLING

The GB30CS-145Li uses steel construction with robotic welding and durable components. This provides a solid machine structure for regular warehouse and industrial use.

FEATURES AND BENEFITS

• 3,000 lb load capacity: Provides the lifting strength needed for heavy pallet handling.
• 145-inch raised height: Gives you the reach needed for higher storage locations.
• Side-shift capability: Allows more precise pallet positioning in tight areas.
• 24V/90Ah lithium battery: Provides long-lasting power with fast charging and zero battery maintenance.
• 39.76-55.55 inch adjustable legs: Helps the stacker accommodate different pallet widths.
• 8.66-32 inch adjustable forks: Gives you flexibility when positioning the forks for different loads.
• 45.3 inch fork length: Provides solid support and reach for palletized loads.
• 24V AC drive motor: Delivers controlled power for daily material handling.
• Curtis controller: Provides electronic control of the drive system.
• Polyurethane wheels: Provide durable rolling performance for warehouse operation.
• Ergonomic handle and controls: Makes the stacker easier to operate throughout the workday.
• Robotic-welded steel construction: Provides a strong structure for regular material handling use.
• 24V/30A charger included: Provides the charging equipment needed for the lithium battery.

SPECIFICATIONS

2-5 days

The GNT GB30CS-145Li includes a 3 Year Limited Warranty according to the manufacturer's product specifications.
